7.2.2.2 Signal Standard (Composite output)
The ADM supports both PAL and NTSC output. Setting this to the NTSC mode will make several NTSC related
features available in GUI as shown below.
7.2.3 AUDIO
The various audio languages available for a selected service are located in the respective drop down list. All
available audio languages will be displayed, either as separate stereo streams or as dual mono streams. In dual
mono streams, the L and R channels carry different languages. The user interface will notify if the selected
service carries dual mono audio; the selected language will be output on both the L and R audio channels.
The MPEG-2/4 SD/HD SDI Decoder supports decoding of two stereo audio tracks labeled Audio1 and Audio 2.
Both audio tracks can be embedded into the SDI stream.
