APPEAR AS Confidential 262/352
9.6 OSDM (ON SCREEN DISPLAY MESSAGE) SUPPORT
On the EC-400, TC-200 and TC-400 modules, it is possible to enable an OSDM (On Screen Display Message) on
the output service.
Once a text string and its options have been configured on the OSDM page in the GUI (see section 7.5), then it
can be assigned to an encoder/transcoder service from the ‘Available’ pool of services.
Font size of OSDM can also be adjusted as per options available in drop down list.
9.7 AUDIO PROCESSOR MODULE
The Audio Processor module (AP-100) allows both the encoding of SDI Embedded and AES67 audio along with
audio transcoding from any input module.
The following codecs and bitrates are supported
