The following parameters are available if enabled:
Bitrate
Bitrate in Mbps. This parameter is mandatory in Semi-transparent mode for IP
output.
PID Control
When Semi-transparency is enabled, it is possible to both:
- Stop PIDs from the transparent input source
- Re-map PIDs from the transparent input source to a different PID ID
- Import PIDs from another input source to the transparent output.
It is possible to add multiple rules by clicking on the icon
Exclude Services
See below
PSI Regeneration
Depending on the Semi-transparent options chosen, it may be required to
regenerate the following PSI tables:
- PAT
- SDT-Actual/Other
- NIT-Actual
This option is available to be enabled/disabled per table.
8.5.5 SERVICE FILTERING IN SEMI-TRANSPARENT MODE
Service filtering in Semi- Transparent mode enables user to enter SID of the services to be stopped. It is possible
to click magnifying icon and select from list of services found on the input. When a service is added to the filter
list, the following will occur:
• All PIDs that are part of a filtered service will be stopped.
• PIDs shared with non filtered services are not stopped.
• PIDs explicitly mapped through/remapped by user (in the PID Import/Remap section), that belongs to a
filtered service, will not be stopped.
• If PAT re-generation is enabled, PMT PIDs of the filtered services is stopped.
