3.3.13 AUDIO PROCESSOR
The Audio Processor module in SDI Encoder mode had 4 BNC inputs. These ports each accept an SDI input which
can contain up to 8 embedded AES audio pairs.
3.4 CONNECTING PROCESSING MODULES
3.4.1 EPG
The EPG Module is available as two different hardware options, EP-100 (ASIO based) and EP-110 (Bamboo
based). If required, this module can be connected to an IP network to facilitate EPG Schedule import and export
and if this is required, the following ports will need to be connected:
• EP-!00: Control Port
• EP-110: Dataport A
3.5 CONNECTING OUTPUT SIGNALS
3.5.1 IP OUTPUT
This applies to the following modules:
• Standalone IP Output
• Dual IP module (Output mode)
standalone IP output card is equipped with both an electrical connector (RJ45) and one optical (via the SFP
module) for data. The RJ45 connector marked “control” is not in use. It is not required to configure the IP address
or connect the port to the IP network.
The Dual IP module is equipped with two electrical connectors (RJ45) and two SFP connector.
Automatic sensing of 100/1000Mbit Ethernet connections is supported. For a 1000Mbit connection, the Ethernet
cable must be a category 6 cable.
The IP address for both the electrical (RJ45) and the optical (SFP) connectors for data is the same. Consequently,
both connectors cannot be used simultaneously. These inputs are automatically activated by IP connection. The
first port activated (by establishing a link to the router) will be the active port. To activate the other port, remove
the cable from the active port.
3.5.2 ASI OUTPUT
Each ASI output module has four independent ASI outputs. The ASI connector is a 75Ω BNC connector. The
maximum output rate per connector is 212Mbit/s in burst mode.
3.5.3 QAM OUTPUT
Each QAM output module has two 75Ω F connectors which carry up to sixteen frequencies.
