APPEAR AS Confidential 52/352
Subnet Mask
Subnet mask
Auto Negotiation
Enabled or disabled
Link Speed
Choose from:
• Max
• 100
• 1000
Current Link Speed
Current detected link speed of the Ethernet interface
Enable ICMP
By default all ports on the Dataport are closed (ie firewall). Enabling this option
enables the port for ‘ping’ to be open. See further details in 4.1.4.
VLANs
The IP Input and IP Output ports can support up to 25 Virtual LANs (VLANs)
depending on the module type and they can be defined in the Admin Properties
view. The VLANs may then be associated with IP input streams when configuring
input multicasts. To add and remove VLANs, click edit. The dialog below will be
displayed:
Click to add VLAN tags and to remove them.
If an active VLAN is removed, the associated IP inputs are reset so that they will not be
part of that particular VLAN group.
Save the settings and connect the unit to your local network. Reconnect to the Web GUI using the MMI address.
Please note that the following addresses ranges are reserved for internal use and not
available to be configured:
Switch: 192.168.0.xxx
Switch w/ IP: 192.168.0.xxx and 192.168.2.xxx
4.1.2 IPV6 ADDRESS SUPPORT
IPv6 support is available for management and data ports of the Switch module, both Control and IP versions. The
following options are supported:
• Support for simultaneous IPv4 and IPv6 addresses, both for management and data ports.
• Management (GUI/SNMP) using IPv6 address
• IP inputs using IPv6 addresses
• IP output using IPv6 addresses
