8.4.6 COFDM OUTPUT MODULE
For COFDM modules, the Port Settings tab is shown below:
The COFDM output module outputs four modulated channels carrying one MPTS each. The module is equipped
with two physical RF connectors: the first two channels A and B, output on the port marked as A+B; the last two
channels C and D output on the port marked as C+D.
The Port Settings tab for a COFDM module allows for modulation settings of each individual channel to be
modified.
The following parameters are available:
1/2, 2/3, 3/4, 5/6, or 7/8
