When replacing a module with a different module type, a mismatch will occur. This will be shown both in the
alarms and in the About page. A DVB-S/S2 module however, can replace a QPSK module. When this happens, a
convert button will show up in the About page along with the remove button. Clicking this button will enable
the DVB-S/S2 module to inherit the configuration of the old QPSK module.
It is not possible to undo this process from the web GUI.
14.4 IMPORTING AND EXPORTING CHASSIS CONFIGURATION
The configuration of a unit can be saved onto a file to be retrieved later. This file contains the entire
configuration, including the MMI IP address. To save the current configuration, click Export (see Figure 14.3).
To retrieve the configuration from an existing file, select the file by clicking Browse. Then, check Include local IP
addresses if the IP addresses should be included, and click Restore.
Figure 14.2- Saving Importing and Exporting Chassis Configuration
This feature has two benefit::
o To restore a unit to a previous state, or
o To use the same setup on multiple units
Use the Include local IP addresses option to bring a unit back to a previous state when lots of changes need to
be undone; or if an upgrade has been unsuccessful.
It is recommended that the configuration be exported before each upgrade and restored after a downgrade (if
the downgrade was unsuccessful).
To use the same setup on multiple units, uncheck the Include local IP addresses option. This way, only one unit
needs to be configured, and all the other units will use the same configuration – but on their existing IP
addresses.
14.5 MAINTENANCE CENTER ACCESS
It is possible to allow/block access to the Maintenance center. A specific access point IP address can also be
specified if required.
