5.4.2 DVB-S/S2/S2X INPUT
Each DVB-S/S2 module can receive up to four individual L-Band satellite input streams. The DVB-S/S2 module
options are summarised below:
Parameter
DVB-S2 In (SR-100)
DVB-S2 Advanced (SR-110)
DVB-S2X In (SR-120)
System (standard)
DVB-S, DVB-S2
Auto, DVB-S, DVB-S2
Auto, DVB-S, DVB-S2
Satellite frequency
1
0.950-2.150 GHz
0.950-2.150 GHz
0.950-2.150 GHz
Symbol rate
1-45 MBd
1-45 MBd (32APSK 38
MBd)
1-45 MBd (32APSK 39.9 MBd)
Constellation
2
(DVB-S)
Auto
Auto
Auto
Constellation (DVB-S2)
QPSK, 8PSK
Auto, QPSK, 8PSK,
16APSK, 32APSK
Auto (detects QPSK, 8PSK,
8APSK-L, 16APSK, 16APSK-L,
32APSK, 32APSK-L)
Code Rate
3
(DVB-S)
Auto, 1/2, 2/3, 3/4,
5/6, 7/8
Auto, 1/2, 2/3, 3/4, 5/6, 7/8
Auto
Code Rate (DVB-S2)
Auto, 1/2, 2/3, 3/4,
3/5, 4/5, 5/6, 8/9, 9/10
Auto, 1/2, 1/3, 1/4, 2/3, 2/5,
3/4, 3/5, 4/5, 5/6, 8/9, 9/10
Auto (detects 1/2, 1/3, 1/4, 2/3,
2/5, 3/4, 3/5, 4/5, 5/6, 7/8, 8/9,
9/10, 13/45, 9/20,
8/15, 11/20, 5/9, 26/45, 28/45,
23/36, 25/36, 32/45, 13/18, 11/15,
7/9, 77/90)
Acqusition range
No
Auto, 150 kHz, 1 MHz, 2
MHz, 2.5 MHz, 5 MHz
Auto, 150 kHz, 1 MHz, 2 MHz,
2.5 MHz, 5 MHz
Spectrum inversion
Auto
Auto, Normal, Inverted
Auto
Roll off (DVB-S)
Auto
Auto
Auto
Roll off (DVB-S2)
Auto (detects 0.20,
0.25, 0.35)
Auto, 0.15, 0.20, 0.25, 0.35
Auto (detects 0.05, 0.10, 0.15,
0.20, 0.25, 0.35)
Pilot
On/Off
(auto)
(auto)
Multistream support
No
Yes (id 0-255)
Yes (id 0-255)
Short FEC frame support
No
Yes (auto)
No
PL Scrambling Sequence
Type
No
Gold, Root
Gold, Root
PL Scrambling Sequence
Index
No
0-262141
0-262141
PLP De-encapsulation
No
Yes
Yes
Blindscan
No
No
Yes
To configure the module:
Switch to the Inputs node in the Navigation Pane
