APPEAR AS Confidential 333/352
It is possible to select and deselect information in this view by clicking on the ‘…’ in the top right hand
corner of the title bar. This will bring up the following dialog:
In this list, it is possible to sort the options by dragging the line to the desired location. The optional
information available is described below:
Descrambler module assigned. The notation is <X:Y> where:
• X – descrambler module’s slot position
• Y – descrambler module’s Common Interface (CI) slot
Transcoder module/port assigned to the service
Audio leveling module assigned to the channel
Monitor module used for monitoring the service
13.1.2 OUTPUT VIEW
Expand the Status node in the Navigation Pane and click on the Output View node. The Output View will be
displayed as shown below.
