APPEAR AS Confidential 49/352
4 ADMINISTRATIVE SETTINGS CONFIGURATION
This chapter describes how to conduct initial configuration of the unit, such as setting its IP address, changing the
GUI’s password, setting the unit’s time as well as handling licenses for the modules in the unit.
4.1 ACCESSING THE WEB INTERFACE
All modules in the unit are controlled via the web interface provided with it. The unit Man Machine Interface
(MMI) software runs on the switch module via the connector marked as “Control”
Default MMI IP address is 192.168.1.100. To change the network settings of the device please follow the steps
described below.
Connect a PC directly to the device (the Ethernet port marked “Control” on the switch module) with an Ethernet
cable.
Set the IP address of the Ethernet adapter of the PC to a fixed address in the same segment (e.g. 192.168.1.99).
Refer to the operating system’s manual for details on setting the IP address on the PC.
Start an internet web-browser and type 192.168.1.100 in the address field. This application was developed and
tested to work properly in the following browsers:
• Mozilla Firefox 11.xx and above
• Microsoft Internet Explorer 11 and above
• Opera 9.xx and above
• Google Chrome
Browsers that are not in this list have not been tested for compatibility.
If you have previously connected to a unit with the same IP address, the ARP table on your
computer might be inaccurate. To delete the old ARP entry, type arp-d 192.168.1.100 in a
command prompt.
