APPEAR AS Confidential 140/352
Horizontal Resolution x Vertical Resolution followed by the Frame Rate
(interlaced or progressive)
Video Format Out
Output format for the video
Video Mode Lock
Specifies if Video mode is locked: Yes or No.
Black Picture
Specifies if picture is black: Yes or No.
Frozen Picture
Specifies if picture is Frozen: Yes or No.
Profile and Level
Specifies the Video Profile and Level.
GOP Size
Specifies the Video GOP Size.
GOP Length
Specifies the Video GOP Length.
Video Bitrate
Video Bitrate is mentioned in Mbps.
Subtitling Status
DVD Sub Enabled
Indicates whether DVB subtitles are enabled or not
DVD Sub Receiving
Indicates whether DVB subtitles are received in an incoming stream or
not
DVD Sub Standard
The standard used for the incoming subtitle either DVB or DTG
EBU Sub Enabled
Indicates whether EBU subtitling is enabled or not
VBI/VANC Status
Current AFD Value
The current AFD value is calculated based on the incoming AFD value,
the aspect ratio conversion and video format conversion.
Current WSS Value
The current WSS value is calculated based on the aspect ratio
conversion and video format conversion.
Lines with Closed Caption
Number of lines used for Closed Captioning
Lines with Teletext
Number of lines used for Teletext
Lines with Video Index
Number of lines used for Video Index
Lines with Test Lines
Number of lines used to embed test lines
Lines with VPS
Number of lines used for VPS
Lines with WSS
Number of lines used for WSS
Incoming Closed Caption
Indicates whether Closed Caption is available on the incoming stream
or not
Incoming EBU Subtitling
Indicates whether EBU subtitling is available on the incoming stream
or not
