APPEAR AS Confidential 200/352
• DVB-S2: QPSK, 8PSK,16 APSK, 32 APSK
RF Level
Specify the RF Level in dBm, valid range is -15 – 0 dBm.
Symbol Rate
Specify the symbol rate in MBd, valid range is 1-45 MBd.
Code rate
Specify the Code rate from the list of pull-down options
Roll off
Specify the Roll off from the list of pull-down options
Gold Code Scr.
Sequence
Define the Gold Code Scrambling Sequence number (SM-300 only)
Pilot
Enables the pilot carrier
CW Carrier
Enables Continuous wave signal. This will disable the modulation and only output a
single carrier at the configured frequency
Inverted
Spectrum
If enabled, the output spectrum is inverted
10MHz Ref
Output
Enable embedded 10Mhz output on the output port (SM-300 only)
24V DC Output
Enable 24V DC output on the output port (SM-300 only)
Signaling:
Frequency
Downstream frequency to be signaled in the output NIT
Orbital Position
Ex.19.2
West/East
West or East
Polarization
Lin Horizontal/vertical
Circular Left/ Right
8.4.7.1 Linear Pre-correction on DVB-S/S2 Output.
In order to compensate both linear distortions in the transmission chain, it is possible to adjust the modulator
output to match these characteristics. This is done via the pre-correction configuration page. When using the
linear pre-correction algorithm, both Gain and Group Delay correction is supported.
