APPEAR AS Confidential 211/352
CAT
DVB
500
When CAT is in play mode then the CAT is generated by the
unit.
When the EMM is mapped from the input, using the include
EMM on the Transport node, then the CAT Mode should be
set to stop as the CAT and EMM is copied from the input.
PMT
DVB
ATSC
200
Regenerated from input. Service ID and component PIDs
and PMT PID may be remapped. Table is automatically
updated to reflect any PID filtering/remapping done in the
GUI.
BAT
DVB
1000
Generated by User Input from GUI.
NIT-A
DVB
2000
NIT is generated based on the values entered by user. All
transports defined in the same network will be included in
NIT.
NIT Other is not supported
IF NIT is not enabled then PID 16 (0x0010) will not be
transmitted.
The NIT supports the following descriptors:
• Delivery descriptors
• Logical Channel Descriptors
SDT-A
DVB
1000
Regenerated from input, if available, otherwise generated.
The Service ID, name, provider and type can be modified.
SDT-O
DVB
5000
Content is identical to corresponding SDT-A.
EIT P/F-A
DVB
1000
Regenerated from input
EIT P/F-O
DVB
5000
Regenerated from input. Supported in MPTS mode only.
TDT
DVB
15000
Generated based on system time
TOT
DVB
15000
Generated based on system time
A single TOT with a single Local Time Offset Descriptor can
be defined globally per unit. The playout mode of the
globally defined TOT is still configurable per Transport
Stream.
MGT
ATSC
100
PSIP Master Guide Table. Generated based on currently
active PSIP tables.
TVCT
ATSC
200
Terrestrial Virtual Channel Table, Regenerated based on
input, if available, otherwise generated.
Short Channel Name and program_number can be
modified (use DVB Service Name and Service ID editing -
see section 8.3.7 for details).
Input Service Location Descriptor is regenerated based on
desired PID mapping, but not generated if there is no input.
