APPEAR AS Confidential 318/352
For Transcoder modules, it is only required to define which role the module will have, ie:
Following parameters are present under redundancy properties.
Group redundancy properties-
Enabled
When checked this card is part of the redundancy group.
Role
Either of one: Main/Spare
Input switch properties for Main Card-
Channel A/B
This defines which input port on the switch receives the same signal as
this port on the card.
Input switch properties for Spare Card-
Connected to
This is the output port of the switch which is connected to the input port
of the spare encoder.
