The following parameters are present under Port section:
Enable
Enable the corresponding input port
Name
This parameter allows for each port in a module to be labeled. This label is visible as a
tooltip when the mouse cursor hovers over the port. Port names are shown in the
alarms when a non-empty string is set as the name.
Mode
Select one of the following modes:
o DVB
o DVB (SDT)
o MPEG
o ATSC
o OFF
The default mode is DVB. If the incoming transport stream is not DVB compliant, use
MPEG mode instead.
The following parameters are present under PLP De-Encapsulation section:
Port ID
Specify the Port ID for T2MI stream
PID
This is T2MI stream PID
PLP ID
This is T2MI stream PLP ID of the required stream
Mode
Select one of the following modes:
o DVB
o DVB (SDT)
o MPEG
o ATSC
o OFF
De-jitter
PCR dejitter will be default on when enabling a new de-encapsulation. The user
can choose to specify the PCR PID and to do CBR dejitter if transparent output
routing
