ASTRO VG-871 - Page 129

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
115
38
HDMI AV Mute IF Change
1
"0"=Normal Mode
"1"=Game Mode
*3
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
39
CursTextMoveMode
1
"0"=Normal
"1"=Move with Curs
*4
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877,VG-880, VG-882, VG-884
40
Mouse Speed
1
"0" - "9"
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
41
INC/DEC I/F Change
1
"0"=OFF、"1"=ON
VG-881
42
Trigger Delay Enable
1
40H - 4FH *8
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
43
Trigger Pulse Enable
1
40H - 4FH *8
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
44
Trigger Toggle Enable
1
"0"=Disable、"1"=Enable
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
45
Trigger Toggle Select
1
"0"=1-4ch, "1"=only 1ch
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
46
Trigger Delay Time 0
1-4
"0"-"4095" = 1H-4096H delay
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
47
Trigger Pulse Width 0
1-4
"0"-"4095" = 0H-4095H
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
48
Trigger Pol
1
40H-4FH *9
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
49
Trigger Frame Data
Num
1-2
"0" - "16"
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
Trigger Frame No
1-4
"1" - "1024"
Trigger Frame
OutData
1
"0" - "F"
This setting is set as below.
In case the data number is 3, and frame No. is 100, 101, 102, and
output data is 9, A, B.
"49" : Code
"," : Delimiter
"3" : Data number
"," : Delimiter
"100" : Frame No.1
"," : Delimiter
"9" : Output Data 1
"," : Delimiter
"101" : Frame No.2
"," : Delimiter
"A" : Output Data 2
"," : Delimiter
"102" : Frame No.3
"," : Delimiter
"B" : Output Data 3
50
Digital Video Level
Step(SHIFT)
1-5
"0" - "32767"
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877,VG-882, VG-884
51
Trigger Delay Time 1
1-4
"0"-"4095" = 1H-4096H delay
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
52
Trigger Pulse Width 1
1-4
"0"-"4095" = 0H-4095H
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
53
Trigger Delay Time
Select
1
40H-4FH *10
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
54
Trigger Pulse Width
Select
1
40H-4FH *11
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
