ASTRO VG-871 - Page 130

116
55
CC Overlay Field 1 Line
1
"0"=19/21
"1"=20/22
"2"=21/23
"3"=22/24
VG-870,VG-871,VG-873,VG-874
56
CC Overlay Field 2 Line
1
"0"=282/333
"1"=283/334
"2"=284/335
"3"=285/336
VG-870,VG-871,VG-873,VG-874
57
CF Program Folder No
1-3
"0"=Pro4 folder
"1"-"999"=Prg4ext xxx folder
VG-870,VG-871,VG-873,VG-874, VG-876,
VG-877
58
AV MUTE Mode
1
"0"=Keeping Status
"1"=Pulse
59
VariableDotClock
2-5
"10"-"50000"
VG-870,VG-871
61
Chapter 7 SDI
TimeCode ON/OFF
1
"0"=OFF, "1"=ON
VG-876,VG-877
62
Chapter 8 SDI
TimeCode Hour(h)
1-2
"0"-"23"
VG-876,VG-877
63
Chapter 9 SDI
TimeCode Min(m)
1-2
"0"-"59"
VG-876,VG-877
64
Chapter 10 SDI
TimeCode Sec(s)
1-2
"0"-"59"
VG-876,VG-877
65
S-TRIG 0 Mode
1
"0"=OFF
"1"=HSync trigger
"2"=VSync trigger
"3"=Field trigger
"4"=DataENABLE trigger
"5"=RGB data trigger
"0"=OFF
"1"=HSync trigger (P)
"2"=HSync trigger (N)
"3"=VSync trigger (P)
"4"=VSync trigger (N)
"5"=Field trigger (2nd)
"6"=DataENABLE trigger (H&V)
"7"=DataENABLE trigger (H)
"8"=DataENABLE trigger (V)
VG-876,VG-877
66
Chapter 11 S-TRIG 1
Mode
1
* Same as Code65
VG-876,VG-877
67
Chapter 12 S-TRIG 2
Mode
1
* Same as Code65
VG-876,VG-877
68
Chapter 13 S-TRIG 3
Mode
1
* Same as Code65
VG-876,VG-877
73
SDI Clock Delay 1
2-3
"00"-"140" *16
VG-876,VG-877
74
SDI Clock Delay 2
2-3
* Same as Code73
VG-876,VG-877
75
SDI Clock Delay 3
2-3
* Same as Code73
VG-876,VG-877
76
SDI Clock Delay 4
2-3
* Same as Code73
VG-876,VG-877
77
SDI Clock Delay 5
2-3
* Same as Code73
VG-876,VG-877
78
SDI Clock Delay 6
2-3
* Same as Code73
VG-876,VG-877
79
SDI Clock Delay 7
2-3
* Same as Code73
VG-876,VG-877
80
SDI Clock Delay 8
2-3
* Same as Code73
VG-876,VG-877
