ASTRO VG-871 - Page 38

24
,
1 byte
2CH (Delimiter)
CS ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
CS MODE
1 byte
“0” = Nega, “1” = Posi
,
1 byte
2CH (Delimiter)
CS Sel
1 byte
“0” = CS, “1” = HS, “2” = VS
,
1 byte
2CH (Delimiter)
CV ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
CV MODE
1 byte
“1” = R, “2” = G, “3” = RG, “4” = B, “5” = RB, “6” = GB,
“7” = “RGB”
,
1 byte
2CH (Delimiter)
Analog Video Level
1 to 3 bytes
“0” to “120” (0.00 to 1.20 V)
,
1 byte
2CH (Delimiter)
Analog Setup Level
1 to 3 bytes
“0” to “25” (0.00 to 0.25 V)
,
1 byte
2CH (Delimiter)
Analog Sync Level
1 to 3 bytes
“0” to “60” (0.00 to 0.60 V)
,
1 byte
2CH (Delimiter)
Out Bit Len
1 or 2 bytes
“0” to “16”
* “0” to “12” in case of VG-882 and VG-883
0: Config setting is followed.
,
1 byte
2CH (Delimiter)
HDCP Disp Port
1 byte
“0” = Disable
“1” = DVI
“2” = PC (DVI)
“3” = HDMI1
“4” = HDMI2
"5" = TV-DVI
"6"=DisplayPort1
"7"=DisplayPort2
"8"=iTMDS1-1
"9"=iTMDS1-2
"10"=iTMDS2-1
"11"=iTMDS2-2
"12"=HDMI3 * VG-882,883, 876
"13"=HDMI4 * VG-882,883, 876
Below is for VG-876
"14"=HDMI5 "15"=HDMI6 "16"=HDMI7
"17"=HDMI8 "18"=HDMI9 "19"=HDMI10
"20"=HDMI11 "21"=HDMI12 "22"=HDMI13
"23"=HDMI14 "24"=HDMI15 "25"=HDMI16
"26"=DisplayPort3 "27"=DisplayPort4
"28"=DisplayPort5 "29"=DisplayPort6
"30"=DisplayPort7 "31"=DisplayPort8
,
1 byte
2CH (Delimiter)
D-Connector Line1
1 byte
“0” = 480, “1” = 720, “2” = 1080, "3" = Auto
,
1 byte
2CH (Delimiter)
D-Connector Line2
1 byte
“0” = Interlace, “1" = Progressive, "2" = Auto
,
1 byte
2CH (Delimiter)
D-Connector Line3
1 byte
“0” = 4:3, “1” = 4:3LB, “2” = 16:9, "3" = Auto
,
1 byte
2CH (Delimiter)
Reserved
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
PC-BNC ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
PC-DSub ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
DVI-A ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
DVI-D ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
VBS ON/OFF
1 byte
“0” = OFF, “1” = ON
,
2CH (Delimiter)
BNC ON/OFF
1 byte
“0” = OFF, “1” = ON
,
2CH (Delimiter)
