Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
25
S-Connector ON/OFF
1 byte
“0” = OFF, “1” = ON
,
2CH (Delimiter)
D-Connector ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
TV-DSUB ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
SCART1 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
SCART2 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
HDMI1 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
HDMI2 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
DVI-D1 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
DVI-D2 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
LVDS-D1 ON/OFF
1 byte
“0” = OFF, “1” = ON
* LVDS1 and LVDS2 are the same.
,
1 byte
2CH (Delimiter)
LVDS-D2 ON/OFF
1 byte
“0” = OFF, “1” = ON
* LVDS1 and LVDS2 are the same.
,
1 byte
2CH (Delimiter)
LVDS-D3 ON/OFF
1 byte
“0” = OFF, “1” = ON
* LVDS3 and LVDS4 are the same.
,
1 byte
2CH (Delimiter)
LVDS-D4 ON/OFF
1 byte
“0” = OFF, “1” = ON
* LVDS3 and LVDS4 are the same.
,
1 byte
2CH (Delimiter)
PARA1 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
PARA2 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
PARA3 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
PARA4 ON/OFF
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
S-Connector
1 byte
“0” = Normal (4:3 normally output)
“1” = LetterBox
“2” = Sqeeze
"3" = Auto
,
1 byte
2CH (Delimiter)
DVI Dual Link Mode
1 byte
“0” = Single (Auto)
“1” = Dual (8 bits)
“2” = Single (8 bits)
“3” = Single (16 bits)
,
1 byte
2CH (Delimiter)
DVI Ctl0
1 byte
“0” = Low, “1” = High
,
1 byte
2CH (Delimiter)
DVI Ctl1
1 byte
“0” = Low, “1” = High
,
1 byte
2CH (Delimiter)
Aspect Mode
1 byte
“0” = 4:3
“1” = 16:9
“2” = Reso
“3” = User
"4" = 4:3 LB
,
1 byte
2CH (Delimiter)
Aspect H
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
Aspect V
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
HDCP Enable
1 byte
“0” = Disable, “1” = Enable
,
1 byte
2CH (Delimiter)
Level Mode1 (Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode2 (PC All)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
