ASTRO VG-871 - Page 40

26
Level Mode3 (TV All)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
Level Mode4 (Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode5 (DVI)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
Level Mode6 (LVDS)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
Level Mode7 (Parallel)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
Level Mode8 (HDMI)
1 byte
“0” = FULL, “1” = LIMITED
,
1 byte
2CH (Delimiter)
Level Mode9 (Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode10
(Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode11
(DisplayPort)
1 byte
"0"=FULL "1"=LIMITTED
,
1 byte
2CH (Delimiter)
Level Mode12
(Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode13
(Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode14（iTMDS）
1 BYTE
"0"=FULL "1"=LIMITTED
,
1 BYTE
2CH（Delimiter）
Level Mode15
(Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Level Mode16
(Reserved)
1 byte
Fixed at “0”
,
1 byte
2CH (Delimiter)
Signal Name Disp On
1 byte
“0” = OFF, “1” = ON
,
1 BYTE
2CH (Delimiter)
DisplayPort1 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
DisplayPort2 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
TV-DVI Digital ON/OFF
1 BYTE
"0"=OFF "1"=ON
iTMDS1 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
iTMDS2 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
SDI 1&2 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
SDI 3&4 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
Digital Video Level
1 - 5 BYTE
"0" to "65535"
* In case of VG-882, 883, it is "0" to"4095"
,
1 BYTE
2CH (Delimiter)
Digital Video Level Bit
Mode
1 - 2 BYTE
"8" - "16"
* In case of VG-882, 883, it is "8" - "12"
,
1 BYTE
2CH (Delimiter)
HDMI3 ON/OFF
1 BYTE
"0"=OFF "1"=ON
,
1 BYTE
2CH (Delimiter)
HDMI4 ON/OFF
1 BYTE
"0"=OFF "1"=ON
ETX
1 byte
03H
Fig. 2-5-1
