42
(2) Character data
Character format
1 byte
“0” = Character List, “1” = All 1 Chara,
“2” = Corner & Center
,
1 byte
2CH (Delimiter)
Character font
1 byte
“0” = 5×7, “1” = 7×9, “2” = 16×16
,
1 byte
2CH (Delimiter)
Character code
2 bytes
“20” to “FF”
,
1 byte
2CH (Delimiter)
H cell size
1 to 3 bytes
“1” to “255”
,
1 byte
2CH (Delimiter)
V cell size
1 to 3 bytes
“1” to “255”
Fig. 2-13-3
(3) Crosshatch data
Mode
1 byte
“0” = No. of lines, “1” = dot
,
1 byte
2CH (Delimiter)
Format
1 byte
“0” = From the center, “1” = From the top left
,
1 byte
2CH (Delimiter)
H interval
1 to 4 bytes
“0” to “9999”
,
1 byte
2CH (Delimiter)
V interval
1 to 4 bytes
“0” to “9999”
,
1 byte
2CH (Delimiter)
H line width
1 or 2 bytes
“1” to “15”
,
1 byte
2CH (Delimiter)
V line width
1 or 2 bytes
“1” to “15”
Fig. 2-13-4
(4) Dot data
Mode
1 byte
“0” = No. of lines, “1” = dot
,
1 byte
2CH (Delimiter)
Format
1 byte
“0” = From the center, “1” = From the top left
,
1 byte
2CH (Delimiter)
H interval
1 to 4 bytes
“0” to “9999”
,
1 byte
2CH (Delimiter)
V interval
1 to 4 bytes
“0” to “9999”
,
1 byte
2CH (Delimiter)
Size
1 or 2 bytes
“1” to “15”
,
1 byte
2CH (Delimiter)
Shape
1 byte
“0” = Round “1” = Square
Fig. 2-13-5
(5) Circle data
Circle format
1 byte
“0” to “6”
Fig. 2-13-6
(6) Burst data
Burst format
1 byte
“0” = L → R, “1” = L ← R, “2” = L ← C → R,
“3” = L → C ← R, “4” = T → B, “5” = T ← B,
“6” = T ← C → B, “7” = T → C ← B
,
1 byte
2CH (Delimiter)
Interval
1 or 2 bytes
“1” to “99”
,
1 byte
2CH (Delimiter)
Step
1 or 2 bytes
“1” to “99”
Fig. 2-13-7
