Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
43
(7) Window data
Window mode
1 byte
“0” = %, “1” = dot
,
1 byte
2CH (Delimiter)
Format
1 or 2 bytes
“0” = 1Window, “1” = 4Window, “2” = 9Window,
“3” = 16Window, “4” = 25Window, “5” = 64Window,
“6” = V3Window, “7” = H3Window, “14” = UserPOS,
“17” = UserPOS2
,
1 byte
2CH (Delimiter)
H width
1 to 4 bytes
% = “1” to “1000” (0.1 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
V width
1 to 4 bytes
% = “1” to “1000” (0.1 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
,
1 byte
2CH (Delimiter)
H-Pos 1
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
V-Pos 1
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
H-Pos 2
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
V-Pos 2
1 to 3 bytes
“0” to “100” (0 to 100%)
Fig. 2-13-8
(8) Cursor data
Shape
1 byte
“0” = 5×5, “1” = Full cross, “2” = Vertical line, "3"=dot
,
1 byte
2CH (Delimiter)
Flicker
1 byte
“0” = None, “1” = 1 V, “2” = 2 V, “3” = 4 V, “4” = 8 V,
“5” = 16 V, “6” = 32 V, “7” = 64 V
,
1 byte
2CH (Delimiter)
Coordinate display
1 byte
“0” = None “1” = Type 1, “2” = Type 2
,
1 byte
2CH (Delimiter)
Step amount
1 byte
“0” = 1 dot, “1” = 10 dots, “2” = 100 dots
,
1 byte
2CH (Delimiter)
R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
,
1 byte
2CH (Delimiter)
Sub-pixel mode
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
Overlay setting
1 byte
“0” = OFF
(Background color provided on background)
“1” = ON
(Other selected pattern provided on background)
,
1 byte
2CH (Delimiter)
Cross point color
1 byte
“0” = Normal (Not set to black)
“1” = Space (Set to black)
,
1 byte
2CH（Delimiter）
Cursor 2Mode
1 byte
"0"=OFF "1"=ON
,
1 byte
2CH（Delimiter）
R Cursor 2Mode
1 to 5 byte
"0" to "65535"
