ASTRO VG-871 - Page 58

44
,
1 byte
2CH（Delimiter）
G Cursor 2Mode
1 to 5 byte
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
B Cursor 2Mode
1 to 5 byte
"0" to "65535"
Fig. 2-13-9
(9) Pattern name
Type
1 byte
“0” = Name
“1” = TIM LIST
“2” = HDMI LIST
“3” = HDCP LIST
“4” = CEC
“5” = DDC_CI
“6” = EDID
“7” = EDID (HEX)
"8" = Image
"9" = OPT User
"10" = DP
"11" = DP (HEX)
"12"=SubTitle, “13”= HDMI-ARC
,
1 byte
2CH (Delimiter)
Position
1 byte
“0” = Center, “1” = L-T, “2” = L-B, “3” = R-T, “4” = R-B,
“5” = C-T, “6” = C-B
,
1 byte
2CH (Delimiter)
Font
1 byte
“0” = 5×7, “1” = 7×9, “2” = 16×16
,
1 byte
2CH (Delimiter)
Length
1 or 2 bytes
“1” to “20”
,
1 byte
2CH (Delimiter)
Format
1 byte
“0” = Program number + Program name
“1” = Program number + Pattern name
“2” = Program number + Program name
+ Pattern name
“3” = Program number + Program name + H/V period
+ Resolution + DotClock
,
1 byte
2CH (Delimiter)
String
20 bytes
* 20 ASCII characters (When the string contains
fewer than 20 characters, enter a space or spaces
after the characters to bring the number of
characters up to 20)
,
1 byte
2CH (Delimiter)
Over Scan H
1 or 2 bytes
“1” to “20” (%)
,
1 byte
2CH (Delimiter)
Over Scan V
1 or 2 bytes
“1” to “20” (%)
,
1 byte
2CH（Delimiter）
DP Block No
1 byte
"0" to "7"
Fig. 2-13-10
(10) Color bar data
TYPE
1 byte
“0” = Custom (Refer to the color bar parameters),
“1” = 100/100-H
“2” = 100/75-H
“3” = 75/75-H
“4” = SMPTE
“5” = RGBW-V
“6” = xvYCC (4%)
“7” = xvYCC (8%)
“8” = xvYCC (12%)
,
1 byte
2CH (Delimiter)
MODE
1 byte
“0” = %, “1” = dot
,
1 byte
2CH (Delimiter)
Number of lines repeated
1 or 2 bytes
“0” to “16”
,
1 byte
2CH (Delimiter)
H width
1 to 4 bytes
% = “0” to “1000” (0.0 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
V width
1 to 4 bytes
% = “0” to “1000” (0.0 to 100.0%), dot = “1” to “9999”
