ASTRO VG-871 - Page 59

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
45
,
1 byte
2CH (Delimiter)
Direction H/V
1 byte
“0” = Horizontal, “1” = Vertical,
“2” = Repeated horizontally, “3” = Repeated vertically
,
1 byte
2CH (Delimiter)
Color specification
1 byte × 16
“0” = None, “1” = R, “2” = G, “3” = RG, “4” = B,
“5” = RB, “6” = GB, “7” = RGB
,
1 byte
2CH (Delimiter)
Level 0
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 1
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 2
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 3
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 4
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 5
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 6
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 7
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 8
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 9
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 10
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 11
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 12
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 13
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 14
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 15
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
Fig. 2-13-11
