Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
53
(6) Burst data
STX
1 byte
02H
TRDT
1 byte
10H
Burst format
1 byte
“0” = L → R, “1” = L ← R, “2” = L ← C → R
“3” = L → C ← R, “4” = T → B, “5” = T ← B
“6” = T ← C → B, “7” = T → C ← B
,
1 byte
2CH (Delimiter)
Interval
1 or 2 bytes
“01” to “99”
,
1 byte
2CH (Delimiter)
Step
1 or 2 bytes
“01” to “99”
Fig. 2-14-7
(7) Window data
STX
1 byte
02H
TRDT
1 byte
10H
Window mode
1 byte
“0” = %, “1” = dot
,
1 byte
2CH (Delimiter)
Format
1 or 2 bytes
“0” = 1Window, “1” = 4Window, “2” = 9Window,
“3” = 16Window, “4” = 25Window, “5” = 64Window,
“6” = V3Window, “7” = H3Window, “14” = UserPOS,
“17” = 1 window + size, variable in any way
,
1 byte
2CH (Delimiter)
H width
1 to 4 bytes
% = “1” to “1000” (0.1 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
V width
1 to 4 bytes
% = “1” to “1000” (0.1 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
,
1 byte
2CH (Delimiter)
H-Pos 1
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
V-Pos 1
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
H-Pos 2
1 to 3 bytes
“0” to “100” (0 to 100%)
,
1 byte
2CH (Delimiter)
V-Pos 2
1 to 3 bytes
“0” to “100” (0 to 100%)
Fig. 2-14-8
