54
(8) Cursor data
STX
1 byte
02H
TRDT
1 byte
10H
Shape
1 byte
“0” = 5×5, “1” = Full cross, “2” = Vertical line
“3” = dot
,
1 byte
2CH (Delimiter)
Flicker
1 byte
“0” = None, “1” = 1 V, “2” = 2 V, “3” = 4 V, “4” = 8 V,
“5” = 16 V, “6” = 32 V, “7” = 64 V
,
1 byte
2CH (Delimiter)
Coordinate display
1 byte
“0” = None, “1” = Type 1, “2” = Type 2
,
1 byte
2CH (Delimiter)
Step amount
1 byte
“0” = 1 dot, “1” = 10 dots, “2” = 100 dots
,
1 byte
2CH (Delimiter)
R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Background B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
,
1 byte
2CH (Delimiter)
Sub-pixel mode
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
Overlay setting
1 byte
“0” = OFF
(Background color provided on background)
“1” = ON
(Other selected pattern provided on background)
,
1 byte
2CH (Delimiter)
Cross point color
1 byte
“0” = Normal (Not set to black)
“1” = Space (Set to black)
,
1 byte
2CH (Delimiter)
Cursor 2Mode
1 byte
“0” = OFF, “1” = ON
,
1 byte
2CH (Delimiter)
R Cursor 2Mode
1-5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G Cursor 2Mode
1-5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B Cursor 2Mode
1-5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Fig. 2-14-9
