ASTRO VG-871 - Page 70

56
,
1 byte
2CH (Delimiter)
Color specification
1 byte × 16
“0” = None, “1” = R, “2” = G, “3” = RG, “4” = B,
“5” = RB, “6” = GB, “7” = RGB
,
1 byte
2CH (Delimiter)
Level 0
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 1
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 2
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 3
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 4
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 5
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 6
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 7
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 8
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 9
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 10
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 11
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 12
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 13
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 14
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
,
1 byte
2CH (Delimiter)
Level 15
1 to 4 bytes
“0” to “1000” (0.0 to 100.0%)
Fig. 2-14-11
(11) Gray scale data
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“0” = Refer to the parameters
“1” = 8STEP-H
“2” = 16STEP-H
“3” = 32STEP-H
“4” = 8STEP-V
“5” = 16STEP-V
“6” = 32STEP-V
,
1 byte
2CH (Delimiter)
MODE
1 byte
“0” = %, “1” = dot
,
1 byte
2CH (Delimiter)
Valid number
1 or 2 bytes
“1” to “16”
,
1 byte
2CH (Delimiter)
H width
1 to 4 bytes
% = “0” to “1000” (0.0 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
V width
1 to 4 bytes
% = “0” to “1000” (0.0 to 100.0%), dot = “1” to “9999”
,
1 byte
2CH (Delimiter)
Direction H/V
1 byte
“0” = Horizontal & V, “1” = Vertical & H”,
“2” = Horizontal, “3” = Vertical
,
1 byte
2CH (Delimiter)
Level 0
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 1
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 2
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 3
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
