Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
57
Level 4
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 5
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 6
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 7
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 8
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 9
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 10
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 11
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 12
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 13
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 14
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Level 15
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
Fig. 2-14-12
(12) Ramp data
Type
1 byte
“0” = Refer to the parameters
“1” = LINEAR-H
“2” = RGB1
“3” = TURN-H
“4” = LINEAR-V
“5” = RGB2
“6” = Invalid
“7” = LINEAR-256
“8” = RGB3
“9” = LINEAR-GR
“10” = LINEAR-BR
“11” = LINEAR-BG
“12” = LINEAR-RG
“13” = LINEAR-RB
“14” = LINEAR-GB
“15” = LINEAR-HV
"16" = Limited-H
"17" = Limited-V
"18"=H2-UpUp
"19"=H2-DownUp
"20"=H2-UpDown
"21"=H2-DownDown
"22"=V2-UpUp
"23"=V2-DownUp
"24"=V2-UpDown
"25"=V2-DownDown
,
1 byte
2CH (Delimiter)
Direction
1 byte
“0” = H, “1” = V
,
1 byte
2CH (Delimiter)
Number of gray scales
1 byte
“1” to “4”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
,
1 byte
2CH (Delimiter)
Start level of gray scale 1
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
End level of gray scale 1
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Number of line 1
gradations
1 to 4 bytes
“1” to “8192”
,
1 byte
2CH (Delimiter)
