ASTRO VG-871 - Page 72

58
Start level of gray scale 2
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
End level of gray scale 2
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Number of line 2
gradations
1 to 4 bytes
“1” to “8192”
,
1 byte
2CH (Delimiter)
Start level of gray scale 3
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
End level of gray scale 3
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Number of line 3
gradations
1 to 4 bytes
“1” to “8192”
,
1 byte
2CH (Delimiter)
Start level of gray scale 4
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
End level of gray scale 4
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Number of line 4
gradations
1 to 4 bytes
“1” to “8192”
Fig. 2-14-13
(13) Sweep data
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“1” = MBURST100
“2” = MBURST50,
“3” = SWEEP
Fig. 2-14-14
(14) Monoscope data
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“1” = PR-133
“2” = PR-133COL,
“3” = MONOSCOPE
“4” = PHILIPS,
“5” = CHINA
"6" = APDC,
“7” =SDI-CHK
,
1 byte
2CH (Delimiter)
APDC Type
1 BYTE
"1"=APDC1
"2"=APDC2
"3"=APDC3
"4"=APDC4
"5"=APDC5
,
1 byte
2CH (Delimiter)
Rev
1 byte
“0” – “1”
Fig. 2-14-15
