Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
59
(15) Raster data
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“0” = Refer to the parameters
“1” = White
“2” = Red
“3” = Green
“4” = Blue
“5” = Black
“6” = 50%Gray
,
1 byte
2CH (Delimiter)
R
1 to 3 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 3 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 3 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
Fig. 2-14-16
(16) Checker data
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“1” = DOT×DOT
“2” = BLK×BLK
“3” = SubPixel
,
1 byte
2CH (Delimiter)
Xsize of dot × dot
1 byte
“1” to “8”
,
1 byte
2CH (Delimiter)
Ysize of dot × dot
1 byte
“1” to “8”
,
1 byte
2CH (Delimiter)
Number of BLK × BLK
blocks in X direction
1 or 2 bytes
“2” to “16”
,
1 byte
2CH (Delimiter)
Number of BLK × BLK
blocks in Y direction
1 or 2 bytes
“2” to “16”
,
1 byte
2CH（Delimiter）
Checker color assign
1 byte
"0"=OFF(default color)
"1"=ON(Refer the CHECKER color data)
,
1 byte
2CH（Delimiter）
SubPixelSize X
1 byte
"0" to "3"
,
1 byte
2CH（Delimiter）
SubPixelSize Y
1 byte
"0" to "3"
,
1 byte
2CH（Delimiter）
Reserved1
1 byte
"0"Fix
,
1 byte
2CH（Delimiter）
Reserved2
1 byte
"0"Fix
,
1 byte
2CH（Delimiter）
Color0 R
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Color0 G
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Color0 B
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Color1 R
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Color1 G
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Color1 B
1 to 5 bytes
"0" to "65535"
,
1 byte
2CH（Delimiter）
Edit Bit Mode
1 to 2 bytes
"8" to "16"
Fig. 2-14-17
