(17) Optional pattern data
STX
1 byte
02H
TRDT
1 byte
10H
Internal optional pattern
code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
User optional pattern
code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
Image data code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
Optional pattern type
1 byte
“0” = Internally fixed, “1” = Created by user,
“2” = Image data
,
1 byte
2CH（Delimiter）
Moving data code
1 to 3 bytes
"1" to "200"
Fig. 2-14-18
(18) Background color data
STX
1 byte
02H
TRDT
1 byte
10H
R
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
G
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
B
1 to 5 bytes
“0” to “65535”
,
1 byte
2CH (Delimiter)
Edit Bit Mode
1 or 2 bytes
“8” to “16”
Fig. 2-14-19
(19) Aspect ratio
STX
1 byte
02H
TRDT
1 byte
10H
Type
1 byte
“1” = OverScan, “2” = AFD
Fig. 2-14-20
