Ateis IDA8S User Manual

System Configuration 293
© 2020, ATEÏS. All rights reserved.
Command string = F
STX
Data Section
STX
F
EXT
CS
CR
STX
Data Section
STX
F
EXT
CR
Answer is always (Reply Messenger Fault)
9. Reply Messenger Fault
Command string = Fsnnnn
STX
Data Section
STX
Fsnnnn
EXT
CS
CR
STX
Data Section
STX
Fsnnnn
EXT
CR
s = Messenger body size
Messenger body size
Reply word
Messenger G2A 2L 2.5
L
Messenger G2A 2L 3.5
Messenger G2A 2L 4.5
Messenger G2A 2XL 2.5
X
Messenger G2A 2XL 3.5
Messenger G2A 2XL 4.5
Messenger G2A L 2.5
L
Messenger G2A L 3.5
Messenger G2A L 4.5
Messenger G2A M 2.5
M
Messenger G2A M 3.5
Messenger G2A M 4.5
Messenger G2A XL 2.5
X
Messenger G2A XL 3.5
Messenger G2A XL 4.5
nnnn = fault bit mask
Bit 001 FLASH_ERROR
Bit 002 SPI_FLASH_ERROR
Bit 003 SSI_CPLD_ERROR
Bit 004 SSI_FP_ERROR
Bit 005 SSI_AUDIO_ERROR
Bit 006 I2C_ADS7830_ERROR
Bit 007 I2C_ADT75_ERROR
Bit 008 DSP_SDRAM_ERROR
Bit 009 DSP_COMM_ERROR
Bit 010 DSP_CODE_ERROR
Bit 011 FPGA_COMM_ERROR
Bit 012 INPUT1_20K_ERROR
