IDA8 Global-Net User Manual342
© 2020, ATEÏS. All rights reserved.
.1.3.6.1.4.1.30512.2.12.1
.2
UserFaultName
.1.3.6.1.4.1.30512.2.12.1
.3
UserFaultType
.1.3.6.1.4.1.30512.2.12.1
.4
UserFaultStatus
Content
Details
WatchdogCounter
The counter will increase ev ery 8 seconds.
Author
ATEIS Group
Product
IDA8C
Sy stemTicks
Sy stem running time (ms)
Version
Version 2
Status
Sy stem Global Status
Bit15 = Minor Fault
Bit14 = Major Fault
Bit13 = Primary activ e if RU conf ig
Bit12 = Secondary activ e if RU conf ig
Bit11 = Backup dev ice f ault if RU conf ig
Bit10 = Ethernet cable broken
Bit9 = Ev acuation
Bit8 = NTP serv er disconnection
Bit7 = Sy stem Fault
Bit6 = Local ATEIS Net Backup Mode
Bit5 = Local ATEIS Net Broken
Bit4 = Global ATEIS Net Backup Mode
Bit3 = Global ATEIS Net Broken
Bit2 = By pass Mode
NumLines
The number of speaker line in the sy stem. If there are 5 IDA8 units, the number of line is 8 x 5 = 40 lines.
Lines
The Speaker Line Monitoring
Line
Line Class: Each IDA8 unit has 8 lines (zones).
Node 1 ~ 8 = 1st IDA8
Node 9 ~ 16 = 2nd IDA8
Node 17 ~ 24 = 3rd IDA8
Node 25 ~ 32 = 4th IDA8 ...and so on.
If conf igured the sy stem with ATEIS Global-Nets, the order will local net f irst, then global net. For example, the
sy stem network is: IDA8C(1, 1), IDA8S(1, 2), IDA8S(1, 3), IDA8C(2, 1), IDA8S(2, 2), IDA8C(3, 1).
Node 1 ~ 8 = IDA8 (1, 1) Line 1~8
Node 9 ~ 16 = IDA8 (1, 2) Line 1~8
Node 17 ~ 24 = IDA8 (1, 3) Line 1~8
Node 25 ~ 32 = IDA8 (2, 1) Line 1~8
Node 33 ~ 40 = IDA8 (2, 2) Line 1~8
Node 41 ~ 48 = IDA8 (3, 1) Line 1~8
LineIndex
Line Index uniquely , f rom 1 to N.
LineMajorFault
1 if major f ault, 0 if normal.
The conditions include:
1. Open Circuit
2. Short Circuit
3. Bad Impedance
4. Do Not Get Backup AMP
5. IDA8 Unit Of fline
LineMinorFault
1 if minor f ault, 0 if normal.
The conditions include:
1. Line Leakage
2. Normal AMP Fault, but backup AMP
3. Only Backup AMP Fault
LineOpenFault
1 if open circuit, 0 if normal.
LineShortFault
1 if short circuit, 0 if normal.
LineImpFault
1 if bad impedance by 18/20KHz monitoring, 0 if normal.
LineImp1kFault
1 if bad impedance by 1KHz monitoring, 0 if normal.
LineLeakFault
1 if leakage, 0 if normal.
LineAmpFault
1 if Normal AMP Fault, 0 if normal.
LineAmpBackupFault
1 if Backup AMP Fault, 0 if normal.
NumRemotes
The number of PDC port in the sy stem.
IDA8C series f ix 4 PDC Port.
IDA8S series f ix 2 PDC Port.
For example, there are 2 IDA8C and 5 IDA8S, the number of PDC port is 2 x 4 + 5 x 2 = 18.
Remotes
Remote(PDC) Port Status
Remote
Remote Status Class: Must connect RS485 Input to NPC in the configuration, then set Modbus Ty pe to
Peripheral Input and set Modbus Channel uniquely in the NPC. The node order will f ollow Modbus Channel.
For example, set the1st IDA8C on Modbus Channel 1~4 f or PDC 1~4, set the 2nd IDA8S on Modbus Channel
5~6 f or PDC 1~2, the node order will be:
Node 1 ~ 4 = 1st IDA8C PDC 1~4.
