IDA8 Global-Net User Manual528
© 2020, ATEÏS. All rights reserved.
Step 10: Open the event window and
select the events. "
1. Source Count: Select how many
events you would like to display on
the front panel. IDA8 supports up to
32 event setting on front panel.
2. Name: Change the name events.
3. Type: there are 3 types of events,
including Audio Signal, Fireman and
Message.
4. PreDefine: Select the event.
5. Zones: Select the zones of event.
Go to the "Default" page and tick the
[Enable] option to set "music 1" event
for certain zones paging.
For "Zone Group" event setting,
please follow step 1- step 4 only, then
follow the steps below.
Step 5: click [Integration] tab and
click [Add] button.
Step 6: click [Add] button again on
the window and select the range of
the code. The example here is set
from 1 to 8. Then click [OK].
Step 7: There are 8 codes on the list
and click [...] code 1 button to select
the zones for code 1.
To Next Page
