737 Flight Crew Operations Manual
Flight Instruments, Displays -
Head-Up Display System,
Symbology
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.42.11
SYMBOL NAME MODE REMARKS
Digital runway
elevation
AIII
approach
Displays runway elevation
entered on the HUD control
panel for 5 seconds:
• after AIII mode
selected, or
• runway elevation
value changed during
an AIII mode
approach.
Digital runway
length in feet.
Digital runway
length in meters.
AIII
approach,
AIII
rollout
Displays runway length
entered on the HUD control
panel for 5 seconds:
• after AIII mode
selected, or
• runway length value
changed during an
AIII mode approach.
When AIII mode active and
above 500 feet AGL, display
flashes when runway length
entered is outside of rollout
guidance capability.
Digital runway
remaining in feet
Digital runway
remaining in
meters
PRI
ground,
AIII
rollout
Displays the length of runway
remaining between airplane
and end of runway based on
runway length entered on the
HUD control panel.
Distance to go PRI in
flight,
IMC
Distance to next waypoint.
Selected course
(digital)
All Displayed full time in PRI
mode and for five seconds
after selection in the IMC,
VMC or AIII modes.
ELV 480
LN 9500
or
LN 9500M
RWY
11
500
or
RWY
11
500M
58.4NM
CRS 316
