737 Flight Crew Operations Manual
Performance Dispatch
Takeof f
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP PD.10.9
Takeoff Obstacle Limit Weight
Flaps 5
Sea Level, 30°C & Below, Zero Wind
Based on engine bleed for packs on and anti-ice off
Reference Obstacle Limit Weight (1000 KG)
Obstacle height must be calculated from lowest point of the runway to conservatively account for runway
slope.
OAT Adjustments
Pressure Altitude Adjustments
OBSTACLE
HEIGHT (M)
DISTANCE FROM BRAKE RELEASE (100 M)
25 30 35 40 45 50 55 60 65 70 75
5 75.4 81.8
20 69.6 75.4 79.9 83.4
40 64.4 69.9 74.2 77.8 80.6 82.9 84.7
60 60.4 65.6 70.0 73.5 76.5 78.9 80.9 82.6 84.0 85.2
80 57.1 62.2 66.5 70.0 73.0 75.6 77.7 79.5 81.1 82.4 83.6
100 54.2 59.3 63.5 67.0 70.1 72.7 74.9 76.8 78.4 79.9 81.1
120 51.7 56.7 60.8 64.4 67.4 70.1 72.4 74.3 76.1 77.6 78.9
140 49.5 54.4 58.5 62.0 65.1 67.7 70.1 72.1 73.9 75.5 76.9
160 47.5 52.3 56.4 59.9 63.0 65.6 68.0 70.1 71.9 73.5 75.0
180 45.6 50.4 54.5 58.0 61.0 63.7 66.0 68.2 70.0 71.7 73.2
200 43.9 48.7 52.7 56.2 59.2 61.9 64.3 66.4 68.3 70.0 71.5
220 42.3 47.1 51.1 54.5 57.5 60.2 62.6 64.7 66.7 68.4 70.0
240 45.5 49.5 53.0 56.0 58.7 61.0 63.2 65.1 66.9 68.5
260 44.1 48.1 51.5 54.5 57.2 59.6 61.7 63.7 65.4 67.1
280 42.8 46.7 50.1 53.1 55.8 58.2 60.4 62.3 64.1 65.7
300 41.6 45.5 48.9 51.8 54.5 56.9 59.1 61.0 62.8 64.4
OAT (°C)
REFERENCE OBSTACLE LIMIT WEIGHT (1000 KG)
40 50 60 70 80 90
30 & BELOW 0 0 0 0 0 0
32 -0.6 -0.7 -0.9 -1.1 -1.2 -1.4
34 -1.2 -1.5 -1.8 -2.2 -2.5 -2.8
36 -1.7 -2.2 -2.7 -3.2 -3.7 -4.2
38 -2.3 -3.0 -3.6 -4.3 -5.0 -5.6
40 -2.9 -3.7 -4.6 -5.4 -6.2 -7.0
42 -3.5 -4.5 -5.4 -6.4 -7.4 -8.4
44 -4.0 -5.2 -6.3 -7.5 -8.6 -9.7
46 -4.6 -5.9 -7.2 -8.5 -9.8 -11.1
48 -5.2 -6.6 -8.1 -9.5 -11.0 -12.5
50 -5.7 -7.3 -9.0 -10.6 -12.2 -13.8
ALT (FT)
OAT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 KG)
40 50 60 70 80 90
S.L. & BELOW000000
1000 -1.5 -1.8 -2.1 -2.5 -2.8 -3.2
2000 -2.9 -3.6 -4.3 -5.0 -5.6 -6.3
3000 -4.3 -5.3 -6.3 -7.3 -8.3 -9.3
4000 -5.6 -7.0 -8.3 -9.7 -11.0 -12.4
5000 -6.9 -8.6 -10.3 -11.9 -13.6 -15.2
6000 -8.2 -10.2 -12.2 -14.2 -16.2 -18.1
7000 -9.4 -11.7 -14.1 -16.4 -18.7 -21.0
8000 -10.6 -13.2 -15.9 -18.6 -21.3 -23.9
9000 -11.7 -14.6 -17.6 -20.6 -23.5 -26.5
10000 -12.8 -16.0 -19.3 -22.5 -25.8 -29.0
September 15, 2016
