737 Flight Crew Operations Manual
Landing Gear -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
14.10.2 D6-27370-866-EGP
2 Landing Gear Indicator Lights (bottom)
Illuminated (green) – related gear down and locked.
Note: Landing gear warning horn is deactivated with all gear down and locked.
Note: Landing gear is down and locked as long as one green landing gear
indicator light (center panel or overhead panel) for each gear is
illuminated.
Extinguished – landing gear is not down and locked.
3 LANDING GEAR Lever
UP – landing gear retract.
OFF – hydraulic pressure is removed from landing gear system.
DN – landing gear extend.
4 Override Trigger
Allows LANDING GEAR lever to be raised, bypassing the landing gear lever
lock.
5 LANDING GEAR LIMIT Speed Placard
Indicates maximum speed while operating landing gear and after gear extension.
Landing Gear Indicator Lights
This is a redundant but separate set of landing gear indicator circuits and lights.
GEAR
RIGHT
GEAR
NOSE
GEAR
LEFT
