Boeing 737-800 - Alternate Mode EEC; Alternate Mode EEC Limit Weight; Alternate Mode EEC Max Takeoff %N1

737 Flight Crew Operations Manual
Performance Inflight Chapter PI
Alternate Mode EEC Section 14
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP PI.14.1
Alternate Mode EECfile Highlight
ALTERNATE MODE EEC
Alternate Mode EEC
Alternate Mode EEC
Alternate Mode EEC Limit Weight
Alternate Mode EEC Takeoff Speed Adjustment
Alternate Mode EEC Max Takeoff %N1
Based on engine bleeds for packs on, engine and wing anti-ice on or off
%N1 Adjustments for Engine Bleed
PERFORMANCE
LIMIT
NORMAL MODE PERFORMANCE LIMIT WEIGHT (1000 KG)
46 50 54 58 62 66 70 74 78 82 86
FIELD 43.4 47.3 51.1 54.9 58.7 62.6 66.4 70.2 74.0 77.9 81.7
CLIMB 42.9 46.6 50.4 54.1 57.8 61.6 65.3 69.1 72.8 76.6 80.3
OBSTACLE 43.1 46.8 50.6 54.3 58.0 61.7 65.4 69.1 72.8 76.5 80.2
TIRE 46.0 50.0 54.0 58.0 62.0 65.7 69.7 73.6 77.6 81.6 85.6
BRAKE 46.0 50.0 54.0 58.0 62.0 65.5 69.4 73.4 77.3 81.3 85.2
TAKEOFF SPEEDS
TAKEOFF SPEED ADJUSTMENT
(KTS)
DRY V1 +1
WET V1 +2
VR +1
V2 0
AIRPORT
OAT (°C)
AIRPORT PRESSURE ALTITUDE (FT)
-2000 -1000 0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
60 92.6 93.2 93.6 93.7 93.8 93.9 94.0 94.1 94.0 93.7 93.6 93.5 93.5
55 93.2 93.8 94.3 94.4 94.5 94.6 94.7 94.9 94.7 94.4 94.1 93.5 92.8
50 93.8 94.4 94.9 95.1 95.2 95.4 95.5 95.6 95.5 95.2 94.9 94.4 93.9
45 94.6 95.2 95.6 95.8 95.9 96.1 96.2 96.3 96.2 95.9 95.6 95.3 94.9
40 95.2 95.9 96.4 96.5 96.6 96.7 96.8 97.0 96.9 96.6 96.3 96.2 95.9
35 95.8 96.5 97.2 97.3 97.4 97.5 97.6 97.7 97.6 97.3 97.0 96.9 96.8
30 95.4 96.6 98.1 98.1 98.2 98.2 98.3 98.3 98.2 98.1 97.8 97.7 97.7
25 94.6 95.9 97.3 97.9 98.5 98.6 98.5 98.5 98.5 98.5 98.4 98.4 98.5
20 93.8 95.1 96.6 97.1 97.7 98.0 98.3 98.6 98.6 98.7 98.6 98.6 98.6
15 93.0 94.3 95.8 96.4 97.0 97.3 97.6 97.9 98.3 98.7 98.9 98.9 98.9
10 92.3 93.6 95.0 95.6 96.2 96.5 96.8 97.2 97.5 97.9 98.3 98.8 99.3
5 91.5 92.8 94.2 94.8 95.4 95.8 96.1 96.4 96.8 97.2 97.6 98.1 98.5
0 90.7 92.0 93.4 94.1 94.7 95.0 95.3 95.7 96.0 96.4 96.8 97.3 97.8
-5 89.8 91.2 92.6 93.3 93.9 94.2 94.5 94.9 95.3 95.7 96.1 96.5 97.0
-10 89.0 90.4 91.8 92.5 93.1 93.4 93.8 94.1 94.5 94.9 95.3 95.8 96.2
-15 88.2 89.5 91.0 91.7 92.3 92.6 93.0 93.4 93.7 94.1 94.5 95.0 95.4
-20 87.4 88.7 90.2 90.8 91.5 91.8 92.2 92.6 93.0 93.4 93.7 94.2 94.6
-25 86.5 87.9 89.4 90.0 90.7 91.0 91.4 91.8 92.2 92.6 93.0 93.4 93.8
-30 85.7 87.0 88.5 89.2 89.8 90.2 90.6 91.0 91.4 91.8 92.1 92.6 93.0
-35 84.8 86.2 87.7 88.3 89.0 89.4 89.7 90.2 90.6 90.9 91.3 91.8 92.2
-40 83.9 85.3 86.8 87.5 88.1 88.5 88.9 89.3 89.7 90.1 90.5 90.9 91.4
-45 83.1 84.4 86.0 86.6 87.3 87.7 88.1 88.5 88.9 89.3 89.7 90.1 90.5
-50 82.2 83.5 85.1 85.7 86.4 86.8 87.2 87.7 88.1 88.4 88.8 89.3 89.7
BLEED
CONFIGURATION
AIRPORT PRESSURE ALTITUDE (FT)
-2000 -1000 0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
PACKS OFF 0.7 0.8 0.8 0.9 0.9 0.9 1.0 1.0 1.0 1.0 1.0 1.0 1.0
September 15, 2016
