3 Current Altitude
Displays current altitude in increments of thousands, hundreds and twenty feet:
• for positive values of altitude below 10,000 feet, a green crosshatch
symbol is displayed
• a negative sign appears when altitude below zero feet is displayed
• readout box becomes bold to denote altitude acquisition
• readout box is highlighted in amber and flashes to denote altitude
deviation (refer to Chapter 4, Automatic Flight and Chapter 15,
Warning Systems).
4 Metric Selected Altitude Readout (readout–magenta, metric symbol–
cyan)
Displays MCP altitude in meters when MTRS is selected on the EFIS control
panel.
5 Selected Altitude (magenta)
Displays the altitude set in the MCP altitude window.
The selected altitude box appears in white during an altitude alert. For more
information, refer to Chapter 15, Warning Systems.
Barometric Indications
1 Barometric Settings (green)
Indicates the barometric setting in either inches of mercury (IN) or hectopascals
(HPA) as selected on the EFIS control panel.
Display is boxed amber if numeric is set and airplane is climbing above transition
altitude, or if STD is set and descending below transition flight level.
2 Preselected Barometric Setting (white)
STD is displayed when the Barometric Standard (STD) switch is selected on the
EFIS control panel.
