737 Flight Crew Operations Manual
Hydraulics -
System Description
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
13.20.2 D6-27370-866-EGP
A and B Hydraulic Systems
Components powered by hydraulic systems A and B are:
A and B Hydraulic System Pumps
Both A and B hydraulic systems have an engine–driven pump and an AC electric
motor–driven pump. The system A engine–driven pump is powered by the No. 1
engine and the system B engine–driven pump is powered by the No. 2 engine. An
engine–driven hydraulic pump supplies approximately 6 times the fluid volume of
the related electric motor–driven hydraulic pump.
The ENG 1 (system A) or ENG 2 (system B) pump ON/OFF switch controls the
engine–driven pump output pressure. Positioning the switch to OFF isolates fluid
flow from the system components. However, the engine–driven pump continues
to rotate as long as the engine is operating. Pulling the engine fire switch shuts off
the fluid flow to the engine–driven pump and deactivates the related LOW
PRESSURE light.
The ELEC 2 (system A) or ELEC 1 (system B) pump ON/OFF switch controls the
related electric motor–driven pump. If an overheat is detected in either system, the
related OVERHEAT light illuminates.
Note: Loss of an engine-driven hydraulic pump and a high demand on the
system may result in an intermittent illumination of the LOW PRESSURE
light for the remaining electric motor-driven hydraulic pump. The flight
control LOW PRESSURE light, Master Caution light, and the FLT CONT
and HYD system annunciator lights also illuminate.
System A System B
ailerons
rudder
elevator and elevator feel
flight spoilers
(two on each wing)
ground spoilers
alternate brakes
No. 1 thrust reverser
autopilot A
normal nose wheel steering
landing gear
power transfer unit (PTU).
ailerons
rudder
elevator and elevator feel
flight spoilers
(two on each wing)
leading edge flaps and slats
trailing edge flaps
normal brakes
No. 2 thrust reverser
autopilot B
alternate nose wheel steering
landing gear transfer unit
autoslats
yaw damper.
March 27, 2014
