737 Flight Crew Operations Manual
Performance Dispatch
Gear Down
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP PD.13.3
Gear Down
Takeoff Obstacle Limit Weight
Flaps 5
Sea Level, 30°C & Below, Zero Wind
Based on engine bleed for packs on and anti-ice off
Reference Obstacle Limit Weight (1000 KG)
Obstacle height must be calculated from lowest point of the runway to conservatively account for runway
slope.
OAT Adjustments
OBSTACLE
HEIGHT (M)
DISTANCE FROM BRAKE RELEASE (100 M)
25 30 35 40 45 50 55 60 65 70 75
5 74.2
20 67.7 72.3
40 62.3 66.8 70.3 72.9 75.0 76.5
60 58.3 62.7 66.2 69.1 71.3 73.2 74.7 75.9
80 55.0 59.4 63.0 65.9 68.3 70.3 71.9 73.3 74.4 75.4 76.3
100 52.3 56.6 60.2 63.1 65.6 67.7 69.4 70.9 72.2 73.3 74.3
120 49.9 54.2 57.8 60.7 63.2 65.4 67.2 68.8 70.2 71.4 72.4
140 47.7 52.0 55.6 58.6 61.1 63.3 65.2 66.8 68.3 69.6 70.7
160 45.7 50.1 53.6 56.6 59.2 61.4 63.3 65.0 66.5 67.9 69.0
180 44.0 48.3 51.8 54.8 57.4 59.7 61.6 63.4 64.9 66.3 67.5
200 42.3 46.6 50.2 53.2 55.8 58.1 60.1 61.8 63.4 64.8 66.0
220 45.1 48.6 51.7 54.3 56.6 58.6 60.4 62.0 63.4 64.7
240 43.6 47.2 50.2 52.9 55.2 57.2 59.0 60.6 62.1 63.4
260 42.3 45.8 48.9 51.5 53.8 55.9 57.7 59.3 60.8 62.2
280 44.6 47.6 50.3 52.6 54.6 56.5 58.1 59.6 61.0
300 43.4 46.4 49.1 51.4 53.5 55.3 57.0 58.5 59.9
OAT (°C)
REFERENCE OBSTACLE LIMIT WEIGHT (1000 KG)
40 45 50 55 60 65 70 75
30 & BELOW 0 0 0 0 0 0 0 0
32 -0.6 -0.7 -0.8 -0.9 -1.0 -1.1 -1.2 -1.3
34 -1.1 -1.3 -1.5 -1.7 -1.9 -2.1 -2.3 -2.5
36 -1.7 -2.0 -2.3 -2.6 -2.9 -3.2 -3.5 -3.8
38 -2.2 -2.6 -3.0 -3.4 -3.8 -4.2 -4.6 -5.0
40 -2.8 -3.3 -3.8 -4.3 -4.8 -5.3 -5.8 -6.3
42 -3.4 -3.9 -4.5 -5.1 -5.7 -6.3 -6.8 -7.4
44 -3.9 -4.6 -5.2 -5.9 -6.5 -7.2 -7.9 -8.5
46 -4.5 -5.2 -5.9 -6.7 -7.4 -8.2 -8.9 -9.6
48 -5.0 -5.8 -6.6 -7.5 -8.3 -9.1 -9.9 -10.7
50 -5.6 -6.5 -7.4 -8.3 -9.2 -10.1 -11.0 -11.9
