737 Flight Crew Operations Manual
Flight Management, Navigation -
ATC Data Link
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
11.34.58 D6-27370-866-EGP
ATC Uplink Message
An uplinked ATC message will be accompanied by a white •ATC message on the
primary engine display and a Hi/Lo chime over the flight deck loudspeaker. ATC
MSG will also be displayed at LSK 6R on the MCDU.
The •ATC message is displayed when an uplink message from the current ATC
controlling authority is received by the communication management unit.
1 •ATC Uplink Message (white)
Indicates receipt of an uplinked ATC message. Hi/Lo chime is sounded and ATC
MSG is displayed at LSK 6R on the CDU.
The •ATC message will continue to be displayed as long as any pending ATC
uplink messages remain in the queue.
September 15, 2016
