737 Flight Crew Operations Manual
Warning Systems -
Controls and Indicators
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
15.10.6 D6-27370-866-EGP
1 Landing Gear Warning Cutout Switch
Push – silences landing gear configuration warning aural indication at flaps up
through 10 and above 200 feet RA.
Note: The aural indication cannot be silenced with the cutout switch at flaps
greater than 10.
Altitude Alert
1 Selected Altitude Alert
A white box shows around the selected altitude display between 900 feet and 300
feet before reaching the selected altitude.
2 Current Altitude Alert
The white box around the current altitude display becomes bold between 900 feet
and 300 feet before reaching the selected altitude.
The box turns amber and flashes for 300 feet to 900 feet deviation from the
selected altitude.
CAPTAIN’S PFD
FIRST OFFICER’S PFD
1
2
September 15, 2016
