Boeing 737-800 - Go-Around Climb Gradient

737 Flight Crew Operations Manual
Performance Dispatch
Landing
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
PD.12.6 D6-27370-866-EGP
ENGINE INOP
ADVISORY INFORMATION
Go-Around Climb Gradient
Flaps 15, Gear Up
Based on engine bleed for packs on and anti-ice off
Gradient Adjustment for Weight (%)
Gradient Adjustment for Speed (%)
With engine bleed for packs off, increase gradient by 0.4%.
With engine anti-ice on, decrease gradient by 0.1%.
With engine and wing anti-ice on, decrease gradient by 0.3%.
When operating in icing conditions during any part of the flight with forecast landing temperatures below
10°C decrease gradient by 1.0%.
OAT (°C)
REFERENCE GO-AROUND GRADIENT (%)
PRESSURE ALTITUDE (FT)
0 2000 4000 6000 8000 10000
54 3.09
50 3.77 2.70
46 4.27 3.35 2.30
42 4.78 3.82 2.90 1.84
38 5.30 4.30 3.34 2.37 1.27
34 5.83 4.80 3.81 2.80 1.65 0.73
30 6.38 5.27 4.20 3.17 2.07 1.15
26 6.41 5.63 4.49 3.45 2.42 1.48
22 6.44 5.65 4.71 3.64 2.66 1.71
18 6.46 5.67 4.72 3.82 2.82 1.87
14 6.49 5.68 4.74 3.83 2.96 2.01
10 6.51 5.70 4.75 3.84 2.97 2.15
6 6.53 5.71 4.76 3.85 2.98 2.16
2 6.55 5.73 4.78 3.86 2.99 2.17
WEIGHT
(1000 KG)
REFERENCE GO-AROUND GRADIENT (%)
012345678
80 -2.31 -2.61 -2.91 -3.19 -3.47 -3.73 -3.99 -4.25 -4.49
75 -1.89 -2.12 -2.36 -2.58 -2.81 -3.03 -3.24 -3.44 -3.65
70 -1.36 -1.53 -1.69 -1.85 -2.01 -2.17 -2.32 -2.47 -2.62
65 -0.73 -0.82 -0.91 -0.99 -1.08 -1.16 -1.24 -1.32 -1.40
60 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
55 0.83 0.94 1.04 1.15 1.25 1.36 1.46 1.56 1.66
50 1.78 2.02 2.27 2.51 2.75 2.98 3.21 3.44 3.66
SPEED
(KIAS)
WEIGHT ADJUSTED GO-AROUND GRADIENT (%)
012345678
VREF40 -0.24 -0.25 -0.26 -0.27 -0.27 -0.28 -0.28 -0.27 -0.27
VREF40+5 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
VREF40+10 0.13 0.12 0.12 0.13 0.14 0.15 0.17 0.20 0.23
VREF40+15 0.27 0.25 0.25 0.25 0.26 0.28 0.31 0.34 0.38
VREF40+20 0.40 0.38 0.37 0.37 0.37 0.38 0.40 0.42 0.46
VREF40+25 0.54 0.51 0.49 0.47 0.46 0.45 0.45 0.45 0.46
VREF40+30 0.68 0.64 0.61 0.57 0.53 0.49 0.46 0.42 0.39
September 15, 2016
