Boeing 737-800 - Radio Navigation

737 Flight Crew Operations Manual
Flight Instruments, Displays -
PFD/ND – Navigation Displays
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 10.41.5
Radio Navigation
SYMBOL NAME MODE REMARKS
ILS /VOR
Reference
receiver
frequency or
identifier display
(W)
VOR,
VOR CTR,
APP,
APP CTR
Located upper right corner.
Frequency displayed before
the identifier is decoded. The
decoded identifier replaces
the frequency. Medium size
characters for VOR, small
size characters for DME only.
Reference ILS or
VOR course (W)
VOR,
VOR CTR,
APP,
APP CTR
Located upper right corner.
Indicates the VOR course or
ILS localizer course.
Reference VOR
or ILS DME (W)
VOR,
VOR CTR,
APP,
APP CTR
Located upper right corner.
Indicates DME distance to
the reference navaid.
DME distance
(G)
All except
PLN
Located lower left or right
corner. Indicates DME
distance to navaid.
Selected course
pointer (W) and
line (M)
VOR,
APP
Displays selected course as
set by the related MCP course
selector.
Selected course
pointer (W)
TO/FROM
pointer (W)
APP CTR,
VOR CTR
Displays selected course as
set by the related MCP course
selector.
TO/FROM pointer is
displayed when VOR
navigation is being used.
To/from
indication (W)
VOR,
VOR CTR
Displays VOR to/from
indication.
OR
116.80
SEA
CRS 135
DME 24.6
DME
24.6
TO
FROM
March 27, 2014
