Boeing 737-800 - 20 Instrument Panels; Panel Arrangement

737 Flight Crew Operations Manual
Chapter 1Airplane General, Emergency
Equipment, Doors, Windows
Instrument Panels Section 20
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
D6-27370-866-EGP 1.20.1
20 Instrument PanelsInstrument PanelsFile Highlight
Panel Arrangement
On the following pages, circled numbers refer to chapters where information on
the item may be found.
The panels, controls, and indicators shown in this chapter are representative of
installed units and may not exactly match the latest configuration. Refer to the
appropriate chapter system descriptions for current information.
STABILIZER
PUSH-TO-TALK
SWITCH
CAPTAIN CONTROL WHEEL DETAIL
MEMORY DEVICE
WRITING PAD HOLDER
AUTOPILOT DISENGAGE SWITCH
CLIP WITH CHECKLIST
TRIM SWITCH
AFT OVERHEAD PANEL
FORWARD
OVERHEAD
GLARESHIELD
LEFT
FORWARD
FORWARD ELECTRONIC PANEL
CONTROL STAND
RIGHT
PANEL
INSTRUMENT
CENTER
AFT ELECTRONIC PANEL
PANEL
FORWARD
PANEL
PANEL
FIRST
SIDE
OFFICER
PANEL
CAPTAIN
SIDE
PANEL
PANEL
September 28, 2006
