Pilot Seat
The captain and first officer seats are adjustable. The following controls are
provided:
• Seat height
• Thigh pad position
• Seat recline
• Armrest height and stowage
• Back cushion (lumbar support) position
• Headrest position
Four units hold the base of the seat to the aircraft seat tracks. A spring-loaded track
lock lever mechanism sets fore and aft movement on the seat tracks.
ARMREST HEIGHT
HEIGHT
LOCK LEVER
ADJUSTMENT KNOB
(2)
SEAT BACK RECLINE
LUMBAR
LEVER
ADJUSTMENT
(UP/DOWN)
SEAT
TRACKS (4)
PILOT SEAT - OUTBOARD SIDE
PILOT SEAT - INBOARD SIDE
TRACK LOCK
LEVER
THIGH PAD
ADJUSTMENT
LUMBAR
ADJUSTMENT
(IN/OUT)
