PFD Airspeed Indications
Airspeed Indications – General
The PFD airspeed indication displays air data inertial reference system (ADIRS)
airspeed and other airspeed related information.
1 Selected Speed (magenta)
Displays target airspeed:
• indicates the airspeed manually selected in the IAS/MACH window
• indicates the FMC computed airspeed when the IAS/MACH window is
blank.
2 Speed Trend Vector (green)
Tip of arrow indicates predicted airspeed in the next 10 seconds based on the
current airspeed and acceleration.
3 Current Airspeed (white)
Indicates current calibrated airspeed in knots.
24
250
260
300
280
220
200
.595
3
2
1
2
3
4
5
6
7
8
