Boeing 737-800 - Page 320

737 Flight Crew Operations Manual
Performance Dispatch
Gear Down
737-800WSFP1/CFM56-7B26
FAA
Category C/N Brakes
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
PD.13.4 D6-27370-866-EGP
GEAR DOWN
Gear Down
Takeoff Obstacle Limit Weight
Flaps 5
Sea Level, 30°C & Below, Zero Wind
Pressure Altitude Adjustments
Wind Adjustments
With engine bleed for packs off, increase weight by 200 kg.
With engine anti-ice on, decrease weight by 2050 kg.
With engine and wing anti-ice on, decrease weight by 7700 kg (optional system).
ALT (FT)
OAT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 KG)
40 45 50 55 60 65 70 75
S.L. & BELOW00000000
1000 -1.5 -1.7 -1.9 -2.1 -2.2 -2.4 -2.6 -2.8
2000 -3.0 -3.4 -3.8 -4.1 -4.5 -4.9 -5.2 -5.6
3000 -4.2 -4.7 -5.3 -5.8 -6.4 -7.0 -7.5 -8.1
4000 -5.3 -6.0 -6.8 -7.6 -8.3 -9.1 -9.8 -10.6
5000 -6.6 -7.5 -8.4 -9.3 -10.2 -11.1 -12.0 -12.9
6000 -7.8 -8.9 -10.0 -11.0 -12.1 -13.2 -14.2 -15.3
7000 -9.2 -10.4 -11.7 -12.9 -14.1 -15.3 -16.5 -17.8
8000 -10.6 -12.0 -13.3 -14.7 -16.1 -17.5 -18.9 -20.2
9000 -11.7 -13.2 -14.7 -16.3 -17.8 -19.3 -20.9 -22.4
10000 -12.8 -14.4 -16.1 -17.8 -19.5 -21.2 -22.9 -24.6
WIND (KTS)
OAT & ALT ADJUSTED OBSTACLE LIMIT WEIGHT (1000 KG)
40 45 50 55 60 65 70 75
15 TW -9.5 -9.2 -9.0 -8.7 -8.4 -8.2 -7.9 -7.6
10 TW -6.3 -6.1 -6.0 -5.8 -5.6 -5.4 -5.3 -5.1
5 TW -3.2 -3.1 -3.0 -2.9 -2.8 -2.7 -2.6 -2.5
0 00000000
10 HW 1.0 0.9 0.8 0.8 0.7 0.6 0.5 0.4
20 HW 2.1 1.9 1.7 1.5 1.3 1.1 0.9 0.7
30 HW 3.3 3.0 2.7 2.5 2.2 1.9 1.6 1.4
40 HW 4.4 4.1 3.7 3.4 3.1 2.7 2.4 2.0
September 15, 2016
