737 Flight Crew Operations Manual
Flight Instruments, Displays -
Electronic Flight Bag (EFB)
Boeing Proprietary. Copyright © Boeing. May be subject to export restrictions under EAR. See title page for details.
10.65.4 D6-27370-866-EGP
1 Back Key
Returns to the previous level.
2 Main Menu (MENU) key
Displays MAIN MENU.
• Cancels transfer mode [XFR].
3 Bright (BRT) Dim (DIM) Control
Rocker switch, upper portion brighter, lower portion dimmer.
4 Line Select Keys
Selects item next to key.
5 Zoom Keys
Left key is zoom in, right is zoom out. Repeated selection increases or decreases
the zoom level.
6 Page Up (PGUP)/Page Down (PGDN) Keys
Moves up or down within an application where the display exceeds one display
screen in length.
7 Transfer (XFR) Key
• View other pilot’s EFB display on this display
• XFR displays in green text on upper right
• Selections made off-side are seen on the on-side display in real time
• XFR key (second push) exits transfer and returns display to last view
prior to selecting XFR
• MENU key exits transfer and displays the MAIN MENU
• While XFR is selected, all other keys/switches are non-functional
except PWR and MENU.
8 Enter (ENTER) Key
Activates a high-lighted item when applicable.
9 Power (PWR) Switch
Turns the display backlight on or off.
10 Touch sensitive screen
Enables direct selection on the display screen, and in some applications panning
and scrolling.
March 27, 2014
